Reference Manual for the 54 Mbps Wall-Plugged Wireless Range Extender WGX102
3-10 Installing the XE102 and the WGX102
September 2004 202-10042-01
Configuring the WGX102 in Access Point Mode
The figure below shows the menu choices available when the WGX102 Wall-Plugged Range
Extender is in Access Point Mode.
Figure 3-9: Access Point Mode menu
Configuring the LAN IP Setup Options in Access Point Mode
LAN IP Setup is under the Advanced heading on both the Access Point Mode and Router Mode
menus. If you are using the WGX102 in Router Mode, see “Configuring the LAN IP Setup
Options in Router Mode” on page 8-9 for configuration information.
To continue configuring the WGX102 in Access Point Mode, see the
next section on LAN IP Setup and the following chapters:
• Chapter 5, “Wireless Configuration”
• Chapter 6, “Maintenance”
Click the Knowledge Base or the Documentation link under the Web
Support menu to view support information or the documentation for
the range extender. You can also see Chapter 9, “Troubleshooting” for
more assistance.
