Reference Manual for the 54 Mbps Wall-Plugged Wireless Range Extender WGX102
Wireless Configuration 5-11
September 2004 202-10042-01
Restricting Wireless Access by MAC Address
To restrict access based on MAC addresses, follow these steps:
1. Click Wireless Settings in the main menu of the browser interface.
2. In the Wireless Card Access List section, click Setup Access List to display the Wireless Card
Access List.
3. Click Add to go to Wireless Card Access Setup, where you can add a wireless card to the list.
Figure 5-5: Wireless Card Access List Setup
Note: When configuring the WGX102 from a wireless computer whose MAC address
is not in the Trusted PC list, if you select Turn Access Control On, you will lose your
wireless connection when you click Apply. You must then access the range extender
from a wired computer or from a wireless computer that is on the access control list to
make any further changes.
