Reference Manual for the 54 Mbps Wall-Plugged Wireless Range Extender WGX102
3-8 Installing the XE102 and the WGX102
September 2004 202-10042-01
Logging On to Configure the WGX102
1. Connect to the range extender by typing http://192.168.0.101 in the address field of your
browser, then click Enter.
2. For security reasons, the range extender has its own user name and password. When prompted,
enter admin for the user name and password for the password, both in lower case letters. To
change the password, see “Changing the Administrator Password” on page 6-12.
Note: The range extender user name and password are not the same as any user name or
password you may use to log in to your Internet connection.
Figure 3-7: Login window
3. Once you have entered your user name and password, your Web browser should find the
WGX102 Wall-Plugged Range Extender and display the AP/Router page as shown below.
