NETGEAR WNA1000M User Manual

Chapter 2: Network Connections and Wireless Security | 21
N150 Wireless Micro USB Adapter WNA1000M
Wireless Security
Many networks use wireless security. The first time you join a network that uses wireless
security, you must either know its security settings, or use Push 'N' Connect (WPS) for a
WPS-compatible wireless network. The main types of wireless security are:
• Wi-Fi Protected Access 2 Pre-Shared Key (WPA2-PSK)
• Wi-Fi Protected Access Pre-Shared Key (WPA-PSK)
• Wired Equivalent Privacy (WEP)
For more information about wireless security, see the wireless reference document at
http://documentation.netgear.com/reference/enu/wireless/index.htm.
Setting Up WPA2-PSK or WPA-PSK Wireless Security
1. Use the icon to open the Smart Wizard. The Settings tab displays:
2. In the Profile field, select the profile, or type in a profile name.
3. In the Network Name (SSID) field select the network, or enter the SSID.
4. In the Security section, select the WPA2 or WPA setting for the wireless network that you
want to join and enter the passphrase.
5. Click the Save Profile button. All the configuration settings are saved in this profile.
6. Click Apply, and then click Close to exit the Smart Wizard.

NETGEAR WNA1000M Specifications

General

Interface	WLAN
Connectivity technology	Wireless
Chipset	-
Internal	No
Component for	PC/Laptop
Product color	Black
Wi-Fi band	Single-band (2.4 GHz)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Maximum data transfer rate	150 Mbit/s
Minimum processor	Intel® Pentium®
Optical drive required	Yes
Compatible operating systems	Windows 7/XP/Vista (32/64-bit)
Compliance industry standards	IEEE 802.11 b/g/n
Dimensions (W x D x H) (imperial)	0.79 x 0.28 x 0.59 \

Weight and Dimensions

Depth	8 mm
Width	34 mm
Height	17 mm
Weight	4 g
