NETGEAR WNA1000M User Manual

22 | Chapter 2: Network Connections and Wireless Security
N150 Wireless Micro USB Adapter WNA1000M
Setting Up WEP Encryption Security
1. Use the icon to open the Smart Wizard. The Settings tab displays:
2. In the Profile field, select the profile or type in a profile name.
3. In the Network Name (SSID) field, select the network, or enter the SSID.
4. In the Security section, select WEP and then select the WEP encryption strength:
• 64-bit WEP data encryption
• 128-bit WEP data encryption
5. Select Create with Passphrase, and enter the passphrase so that the Smart Wizard will
generate the WEP keys. The characters are case-sensitive. Be sure to use the same
passphrase for all the wireless devices in the network.
If the wireless network that you want to join does not support the passphrase method, you
must enter the keys so that they match the wireless network exactly.
6. Click the Save Profile button.
7. Click Apply and then click Close to exit the configuration utility.

NETGEAR WNA1000M Specifications

General

Interface	WLAN
Connectivity technology	Wireless
Chipset	-
Internal	No
Component for	PC/Laptop
Product color	Black
Wi-Fi band	Single-band (2.4 GHz)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Maximum data transfer rate	150 Mbit/s
Minimum processor	Intel® Pentium®
Optical drive required	Yes
Compatible operating systems	Windows 7/XP/Vista (32/64-bit)
Compliance industry standards	IEEE 802.11 b/g/n
Dimensions (W x D x H) (imperial)	0.79 x 0.28 x 0.59 \

Weight and Dimensions

Depth	8 mm
Width	34 mm
Height	17 mm
Weight	4 g
