NETGEAR WNA1000M User Manual

26 | Chapter 2: Network Connections and Wireless Security
N150 Wireless Micro USB Adapter WNA1000M
c. In the Profile field, type the name of the profile.
d. Click Apply.
3. Save your settings in a profile.
a. Click Save Profile, and all the configuration settings are saved in this profile.
b. Click Apply, then click Close to exit the Smart Wizard, or click Cancel to return to
the previous settings.
4. Configure the computer network settings.
a. Configure each computer with either a static IP address or with the IPX protocol.
b. Restart the computers.
5. Verify wireless connectivity between your peer devices with the ping program:
a. On the Windows taskbar, select Start > Run.
b. Assuming the target PC is configured with 192.168.0.1 as its IP address, type:
ping -t 192.168.0.1
and then click OK.
c. A continuous ping will be sent to the device with the 192.168.0.1 static IP address.
The ping response should change to Reply.
At this point the connection is established.
Note: If you cannot connect, see Removing the Software on page 15. For
problems accessing network resources, the Windows client and rile
and print sharing software might not be installed or configured
correctly on your computers. See the link to Internet Networking and
TCP/IP Addressing: in Appendix B.

NETGEAR WNA1000M Specifications

General

Interface	WLAN
Connectivity technology	Wireless
Chipset	-
Internal	No
Component for	PC/Laptop
Product color	Black
Wi-Fi band	Single-band (2.4 GHz)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Maximum data transfer rate	150 Mbit/s
Minimum processor	Intel® Pentium®
Optical drive required	Yes
Compatible operating systems	Windows 7/XP/Vista (32/64-bit)
Compliance industry standards	IEEE 802.11 b/g/n
Dimensions (W x D x H) (imperial)	0.79 x 0.28 x 0.59 \

Weight and Dimensions

Depth	8 mm
Width	34 mm
Height	17 mm
Weight	4 g
