NETGEAR WNR1000v3 - Wireless- N Router Setup Manual

Manually Installing Your Router 13
5. Locate the Ethernet cable that came with your NETGEAR product. Securely insert one end of
the Ethernet cable into your modem (C) and the other end into the Internet port of the wireless
router (D). (The cable and the Internet port label are color coded.)
6. Locate the cable (A) that is still attached to your computer (see step 4). Securely insert that
cable into a port on the router, such as port 4 (E), as shown in Figure 8.
Figure 7
Figure 8
C
D
A
E
4 3 2 1

NETGEAR WNR1000v3 - Wireless- N Router Specifications

General

WiFi Technology	802.11n
WiFi Speed	Up to 150 Mbps
Frequency Band	2.4 GHz
Power Supply	12V DC, 0.5A
Security	WPA, WPA2
Weight	0.44 lb (0.2 kg)
Ethernet Ports	4 x 10/100 Mbps LAN, 1 x 10/100 Mbps WAN
Dimensions	173 x 128 x 28 mm
