Netis WF-2402 User Manual

150Mbps Wireless-N Broadband Router User Manual
48
4.6.3. Address Reservation
Figure 4-41
 Address Reservation: reserve IP address for designed physical address host. If you want
to configure a fixed IP address for some host, please input physical address and IP
address, then click add.
4.7. Forwarding
4.7.1. Virtual Servers
Figure 4-42
 Description: Describe current virtual server item.
 Internal Host IP Address: The “Internal Host IP Address” indicates IP address of the
internal host using virtual server.
 Protocol: The protocol item supplies several protocols. For example, if you have web
server within LAN, you can select the HTTP template then the router will input port
number 80 automatically.
 External Port: Input an extranet port number (the users in Internet can see these ports).
 Internal Port: Input an intranet port number.
