WF-2406 User Manual
50
Figure 4-39
AP1:
 Select radio mode is WDS or AP+WDS in wireless management-basic of AP1.
 Click on „Wireless Management‟- „AP Setup‟- „Security‟ and select and save None as
authentication type.
 Click on „Wireless Management‟- „AP Setup‟- „Security‟ and select and save None as
WDS authentication type or select a WDS security type, enter key and save.
 Input WDS name (e.g.: default), input MAC address of AP2 (00-22-4f-bc-af-5d), click add,
then the record named default will appears in WDS list.
 Select Channel is „Channel 6‟in wireless management-basic of AP2.
AP2:
 Select radio mode is WDS or AP+WDS in wireless management-basic of AP2.
 The IP address of AP2 should be 192.168.1.x (1<x<255,e.g.: x=8).
 Select „LAN setup‟-„DHCP server‟ ,select disable DHCP server.
 4. Input WDS name (e.g.: Default), input MAC address of AP1 (00-22-4f-cc-ae-f5), click
add, then the record named Default will appears in WDS list.
 Select Channel is „Channel 6‟in wireless management-basic of AP2.
Note: Before you setup WDS connection, please make sure that AP1 and AP2 is in the same
network, that is if the IP address of AP1 is 192.168.1.1, then the IP address of AP2 should be
192.168.1.x (1<x<255,e.g.: x=8).
