PRESENTATION
DESCRIPTION
NetMan plus is a device that allows inverter management through a LAN (Local Area Network); the
accessory supports all the main network protocols (TCP/IP, HTTP and so on) and is compatible
with Ethernet 10/100Mbps IPv4/6 networks. The inverter can therefore be integrated easily into
medium and large-sized networks.
NetMan 101 plus is an accessory which is external to the inverter and connected to it by serial
cable; NetMan 102 plus is an expansion card which is inserted in the inverter slot
The device also records inverter values and events in the history log archive.
A: network port;
B: RS-232 communication port
C: power supply connector
D: connector for connection to the inverter
