PVI config menu
The PVI config menu shows a screen like the one below.
/------------------------/
/ PVI conf /
/------------------------/
PRTK Code......:SISER19601RU
Name...........:PV1
PVI Address....:1
Serial number..:123456
With this menu the inverter parameters must be set as described in the following table, for the
inverter to be able to communicate correctly with the device.
Field
Parameters to be inserted
PRTK Code
SISER19601RU
Name
Enter the identifying name of the inverter
PVI Address
Enter the inverter address for serial communication
(2)
Serial number
Enter the inverter identification code for modem connection
(1)
The PRTK code is formed of 12 alphanumeric characters.
(2)
The serial communication is not supported.
After inserting the data and pressing the “ESC” key to exit from the menu, the settings can be
tested by pressing the “T” key. If the test is performed, a screen like the one shown below is
displayed, with some of the main inverter values. If the values remain at zero, this means that the
inverter and the device are not communicating correctly.
/------------------------/
/ Status /
/------------------------/
PV1 voltage....: 360V
Grid Voltage...: 230V
Press [ESC] to quit
