Miscellaneous menu
The Miscellaneous configuration menu shows a screen like the one below.
/------------------------/
/ Miscellaneous /
/------------------------/
Log frequency..:5
UDP Port.......:33000
sysContact.....:Administrator
sysName........:My Server
sysLocation....:new building
HTTP Port......:80
With this menu further device parameters can be configured as described in the following table.
Field
Parameters to be inserted
Log frequency
Enter the delay, measured in seconds, between one data log and the next
(see paragraph “Datalog”)
UDP Port
Enter the port where the UDP service is started
(1)
sysContact
Enter the string to be associated with these SNMP variables
sysName
sysLocation
HTTP Port
Enter the port for HTTP connection
(1)
This port must be the same as configured in the software.
