INSTALLATION AND CONFIGURATION
JUMPER SETTINGS
The jumpers on the card can be used to:
activate or deactivate the autonegotiation of transmission speed and mode of the Ethernet
network (JP7, JP8, JP9)
select 10/100Mbps or 10Mbps transmission speed (JP7, JP8, JP9)
select half duplex or full duplex transmission mode (JP7, JP8, JP9)
activate automatic netboot on start-up (JP14)
enable the environmental sensors (JP6, JP10)
Refer to the tables and figures below to configure the jumpers correctly.
NetMan 101 plus
NetMan 102 plus
JP1
CLOSED
OPEN
JP2
JP3
OPEN
CLOSED
JP4
JP5
OPEN
JP6
 OPEN = DISABLE ENVIRONMENTAL SENSORS
CLOSED = ACTIVATE ENVIRONMENTAL SENSORS
JP10
 CLOSED 1-2 TO ENABLE THE MODEM
CLOSED 2-3 TO ENABLE THE ENVIRONMENTAL SENSORS
JP11
OPEN
JP12
OPEN
See paragraph INSTALLATION OF
NETMAN 102 PLUS
JP14
 OPEN = AUTOMATIC NETBOOT INACTIVE
CLOSED = AUTOMATIC NETBOOT ACTIVE
(1)
(1)
See paragraph “Firmware update”
NetMan plus
AUTO-NEG
SPEED
(Mbps)
DUPLEX
JP7
JP8
JP9
Deactivated
10
Half
PINS 2-3 closed
PINS 2-3 closed
PINS 2-3 closed
Full
PINS 2-3 closed
PINS 2-3 closed
PINS 1-2 closed
10/100
Half
PINS 2-3 closed
PINS 1-2 closed
PINS 2-3 closed
Full
PINS 2-3 closed
PINS 1-2 closed
PINS 1-2 closed
Activated
only 100
Half
PINS 1-2 closed
PINS 2-3 closed
PINS 2-3 closed
Full
PINS 1-2 closed
PINS 2-3 closed
PINS 1-2 closed
10/100
only Half
PINS 1-2 closed
PINS 1-2 closed
PINS 2-3 closed
Full or Half
 PINS 1-2 closed
 PINS 1-2 closed
 PINS 1-2 closed
The default configurations are shown with the symbol “  ”.
