3-CONTROLSANDINSTRUMENTS
Mid-mounttwo-spoolcontrolvalvelever
Themidmounttwo-spoolcontrolvalve(1)locationisto
theright-handsideoftheinstrumentpanel.Thecon-
trolvalveoperatesthefront-endloaderandotherfront
mountedimplements.
Thecontrolvalveisequippedwithacontrolleverlockout
(2)thatlocksthecontrolvalvehandleintheneutralposi-
tionanddoesnotallowthevalvetooperate.
NHIL17CT00179AA1
Tooperatethecontrolvalve,movethecontrollever(1)in
anyofthefourdirections.
Releasethecontrollevertostopthecylinderinanyposi-
tion,theleverautomaticallyreturnstoneutral.
•
Movethecontrolleverforwardtolowertheloader/re-
tractcylinder(A).
•
Movethecontrollevertothelefttocurlthebucket/re-
tractcylinder(B).
•
Movethecontrolleverrearwardtoraisetheloader/ex-
tendcylinder(C).
•
Movethecontrollevertotherighttodumpbucket/ex-
tendcylinder(D).
Movethecontrolleverfullyforwardto"FLOAT"position
(E)whichallowstheloaderboomliftcylinderstoextend
orretract.Thisvalvepositionwillallowtheloadertofol-
lowthegroundcontourduringoperation.Floatisalsoa
“dented”position,meaningyoumustmanuallyreturnthe
controlvalvelevertotheneuralposition.
NOTE:Donotusethe"FLOAT"position(E)iftheloader
bucketisofftheground.
NHIL17CT01827AA2
3-12
