Newall DP8 - Page 15

Set-Up
Newall Measurement Systems
14
Setting PCD (Bolt Hole Circle) ON enables the [PCD] func-
tion key on the keypad. If PCD OFF is set, the [PCD] func-
tion on the keypad is disabled.
PCD is explained further in the DP8 Mill Section See Section
6.0 of this manual.
Press the [ > ] key to move to the next menu option.
PCD ON
Options: PCD ON
PCD OFF
PCD
Toggle between (PCD ON) and (PCD OFF
)using the arrow keys and select desired
mode with (ENT).
ent
>
ent
>
Setting LINE (Line Hole Tool) ON enables the [LINE] key
on the keypad. If LINE OFF is set, the [LINE] function on
the keypad is disabled.
Line Hole is explained further in the DP8 Mill Section, See
Section 6.0 of this manual.
Press the [ > ] key to move to the next menu option.
LINE ON
Options: LINE ON
LINE OFF
LINE
Toggle between (LINE ON) and (LINE
OFF) using the arrow keys and select
desired mode with (ENT).
ent
>
ent
>
Setting POLAR (Polar Co-ordinates) ON enables the
[ POLAR ] key on the keypad. If OFF is set, the [POLAR]
function on the keypad is disabled.
Polar Co-ordinates are explained further in the DP8 Mill
Section, See Section 6.0 of this manual.
Press the [ > ] key to move to the next menu option.
POLAR ON
Options: POLAR ON
POLAR OFF
POLAR
Toggle between (POLAR ON) and
(POLAR OFF) using the arrow keys and
select desired mode with (ENT).
ent
>
ent
>
(k) PCD / Bolt Hole Circle (DP8 MILL VERSION ONLY)
(l) Line Hole Tool (DP8 MILL VERSION ONLY)
(m) Polar Co-ordinates (DP8 MILL VERSION ONLY)
Setting TOOL (Tool Offsets) ON enables the TOOL keys
on the keypad. If TOOL OFF is set, the [TOOL] function
on the keypad is disabled.
Tool Offsets are explained further in the DP8 Lathe
Section, See Section 7.0 of this manual.
Press the [ > ] key to move to the next menu option.
TOOL O N
Options: TOOL O N
TOOL OFF
TOOL
Toggle between (TOOL ON) and (TOOL
OFF) using the arrow keys and select
desired mode with (ENT).
ent
>
ent
>
(n) Tool Offset Compensation (DP8 LATHE VERSION ONLY)
