Set-Up
Newall Measurement Systems
13
Setting ARC (Arc Contouring) ON enables the [ ARC ] key
on the keypad. If ARC OFF is set, the [ ARC ] function on
the keypad is disabled.
ARC is explained further in the DP8 Mill Section, See
Section 6.0 of this manual.
Press the [ > ] key to move to the next menu option.
ARC ON
Options: ARC ON
ARC OFF
ARC
Toggle between (ARC ON) and (ARC
OFF) using the arrow keys and select
desired mode with (ENT).
ent
>
ent
>
(j) Arc Contouring (DP8 MILL VERSION ONLY)
SDM (Sub Datum Memory or Stored Dimension Memory)
ON enables the [SDM] function key on the keypad. If SDM
OFF is set, the function key on the keypad is disabled.
SDM is explained further in the Sub Datums Section, See
Section 5.4 of this manual.
S
Press the [ > ] key to move to the next menu option.
SDM ON
Options: ON
OFF
SDM
Toggle between (SDM ON) and (SDM
OFF) using the arrow keys and select
desired mode with (ENT.)
ent
>
ent
>
The further away the scale is mounted from the centre line
of the workpiece, the greater is the potential for linear error.
Linear Error Compensation is expressed as a multiplier,
which is displayed for each axis when LIN COMP is
selected. A factor of 1.000000 indicates no compensation.
True or standard distance moved
The compensation factor is:
Measured distance
A gauge block, standard bar or laser measurement should
be used as the standard against which the displayed
movement is compared.
ZERO
Move the machine to the zero position
of the standard against which the axis is
being compared and zero the axis with
the zero key. Move the machine a
known distance as determined by the
standard and enter that value.
The new compensation factor is auto-
matically calculated and displayed.
ent
Xo
Yo
Zo
>
IMPORTANT:
All measurements will be adjusted according to
the compensation factor entered for each axis.
To disable the adjustment, enter a Linear Error
Compensation factor of one (1.000000).
(i) SDM (Sub Datum Memory / Stored Dimension Memory)
Press the [ > ] key to move to the next menu option.
STANDARD
2 0
Alternatively, the factor may be directly
entered. When (ZERO) is displayed,
use the arrow keys to switch to (ENT
COMP)
Load the required factor.
Use this method to cancel a Linear Error
Compensation factor. Enter a factor of
1.000000. Press (ENT) to accept.
ent
E N T. COMP
0 5
>
. 01
