Newmac WAO E - General Assembly with Optional Blower Assembly

27
27
FIG. 15 – GENERAL ASSEMBLY WITH OPTIONAL BLOWER ASSEMBLY
The blower section can be mounted on the right or left side. The furnace section right and left hand panels are
interchangeable. The fan and limit control mounts on the front corner closest to the blower using the mounting bracket
provided.
