User Manual for AZ110 Broadcast Satellite Modulator with ASI interface
SHAPING THE FUTURE SATELLITE OF COMMUNICATIONS
Connector Back Panel 05 / Description
Connector
Technical Specifications Signalling Type
1. IFL (IN) SMA (Female) 50 Ohm L-band (Input) to be looped to Mod
OUT of BP01
2. IFL (OUT) SMA (Female) 50 Ohm L-band + 10MHz,
Back Panel 06/Description
Connector Technical Specifications Signalling Type
1. RF OUT SMA (Female) 50 Ohm Lower Ku-band
2. L-band OUT SMA (Female) 50 Ohm L-band
3. L-band Ext IN SMA (Female) 50 Ohm L-band
