NDiS 161 User Manual
Chapter 1: Product Introduction
Main Memory
One 25° angled DIMM socket •
Supports DDR2 533/667MHz SDRAM with unbuffered and non-ECC •
memory module
Supports up to 2GB memory•
I/O Interface - Front
DB9 port x1 for RS232•
Power-on LED x1•
HDD LED x1•
DVI-D x1 for DVI output•
ATX Power-on button x1•
Reset button x1•
I/O Interface - Side
DVI x1 (DVI-I for CRT and DVI-D output via Y-cable)•
S-Video x1•
Phone-jack x1 for composite video•
RJ45 with LED x1 for 10/100/1000Mbps Ethernet•
USB x2•
S/PDIF x1•
Phone-jack for line-out x1•
Optional antenna for WiFi x1•
+12V DC-in power x1•
Storage
SATA 2.5” HDD storage x1•
u-DOC x1•
CF type I/II x1 (optional)•
Expansion Slot
1 optional mini PCIe slot for wireless module•
Dimensions
W: 280mm; D: 210mm; H: 40.7mm (without rackmount bracket)•
Construction
Top cover made of aluminum for heat dissipation•
Chassis made of steel - in black•
Power Input
External 80W AC/DC adapter x1•
AC-in: 100~240VAC•
DC-out: DC +12V•
Environment
Operating temperature: Ambient with airflow from 0°C ~ 45°C (HDD •
inside)
Storage temperature: -20°C ~ 60°C, Humidity: 10% ~ 95% @ 40°C •
(non-condensing)
Certification
CE approval•
FCC•
