USB-Link™ 3 Installation and Setup Manual
Chapter 2: Introducing the USB-Link™ 3
Device Features
The images below detail the features of the USB-Link™ 3 Wireless Edition and Wired Edition.
Legend
Figure 2.1 USB-Link™ 3 Wireless and Wired Edition
A – Vehicle Port
B – Power LED
C – Vehicle Data LED
D – Fault LED
E – Wireless Comm LED
F – Pairing Button
G – USB Port
9
A
G
B
C
D
E
F
Wireless Wired
