USB-Link™ 3 Installation and Setup Manual
Chapter 2: Introducing the USB-Link™ 3
Device Features
These features perform the same whether in Bluetooth
®
or Wi-Fi mode:
The Wireless LED and the Pairing Button perform differently depending on which mode (i.e., Bluetooth
®
or Wi-Fi) the device is in.
10
Feature
Vehicle Port
Power LED
Vehicle Data LED
Fault LED
USB Port
Feature
Wireless Comm LED:
Bluetooth
®
Mode
Wireless Comm LED:
Wi-Fi—Mini Access Point Mode
What It Does
Connects the USB-Link™ 3 to a vehicle/engine for
power and data.
Illuminates when the device receives power.
Illuminates when the device is receiving data from
the vehicle.
Illuminates when a problem is detected.
Connects the device to your PC (wired connection).
Latching USB Mini-B Connector for connection to PC host.
Not used with iOS device.
What It Does
If the device is Discoverable:
• Illuminates solid blue when connected.
• Blinks every second when not connected.
If the device is Non-Discoverable:
• Illuminates solid blue when connected.
• Off when not connected.
Mini Access Point Mode:
• Illuminates solid white when a client PC connects to
the device.
• Off when no client PC is connected.
