USB-Link™ 3 Installation and Setup Manual
Chapter 3: Installing the Drivers and Setting Up the Device 37
4 Use the button in the Protocol box to select the appropriate protocol (e.g., J1939, CAN,
ISO 15365, J1708).
- The Protocol box lists only the protocols supported by the device selected in the Device box.
5 Press the Start Test button.
The Device Test screen is refreshed and the Connection Indicator button (located in the bottom
left corner of the display) changes from Not Connected (red) to Connected (green).
The Vehicle Info window displays information about the vehicle to which you are connected
(depending on the protocol selected).
The Modules Detected window in the middle of the screen displays a list of all systems seen on
the bus. It is used for J1308 and J1939 only. For all other protocols this window will be unavailable
(i.e., NOT USED).
The Bus Messages window at the bottom of the screen displays data received from the vehicle bus.
Figure 3.16 Communication Validation Tool: Status Connected
