CMS100 Product Manual, Issue 8
www.nexo.com Page 11
1.8 Relay ratings
Relay
Maximum IEC rating
@100-240VAC
Maximum UL ratings
@ 120VAC
Compressor 10 (10) A, p.f. 0.6 16 FLA, 96 LRA
Lights 4 (4) A, p.f. 0.6 250W ballast
Evaporator fan 4 (4) A, p.f. 0.6 4.4 FLA, 13.1 LRA
Note
This controller is designed for integration into 3rd party equipment only and should
be installed according to these instructions and all relevant local electrical and safety
standards.
1.9 Temperature input ranges
Sensor Input range (°C) Input range (°F)
Appliance sensor -15°C to 50°C +/- 0.5°C 5°F to 122°F +/- 1°F
Condenser sensor 50°C to 125°C +/- 5.0°C 122°F to 257°F +/- 10°F
Evaporator sensor -15°C to 50°C +/- 0.5°C 5°F to 122°F +/- 1°F
Note
The NTC (negative temperature coecient) thermistor from Elstat is rated at:
-35°C to 125°C (-31°F to 257°F).
