22
Step 5:
Remove the pins from the rear rigging
assembly of the bottom cabinet.
This will allow the dolly to swing
free, take care to hold the dolly
to prevent injury.
Step 6:
Remove the front two pins from the
bottom cabinet and the dolly is
free to be removed. The cabinets
can now be raised or additional
cabinets added as required.
4 Mechanical Congurations
