5.4 External Input
WF1945B 5-17
 External AM (EXT-AM) (
SYSTEM
: EXT-AM)
Operation to modulate the WF1945B output with an external AM signal is described. The external signal
is applied to the rear panel EXT AM IN connector.
For details on connectors, “3.2 Input and output connectors (External add input (EXT ADD
IN)”, cf.
Operation:
① Press the
SYSTEM
key, then use the and keys to produce the following display
(EXT-AM flashes).
ＯＦＦ ＯＮ
ＳＹＳＴＥＭ：
3
ＬＯＡＤ ＥＸＴ－ＡＭ ＥＸＴ－ＡＤＤ
4
② Press the
ENTER
key, then use the and keys to produce the following display (ON
flashes).
ＯＦＦ ＯＮ
ＳＹＳＴＥＭ：
3
ＬＯＡＤ ＥＸＴ－ＡＭ ＥＸＴ－ＡＤＤ
4
Note:
• AM appears at the head of the display when external AM is on.
１０００．００００００００Ｈｚ
ＡＭ Ａ０．１０００Ｖｐ－ｐ Ｏ＋０．００００Ｖ ／ＯＰＥＮ
