NF WF1945B - Basic Operation

3.3 Basic operation
WF1945B
3-18
Continued from previous page
Key operation Menu Initial settings Remarks
TYPE FM
FREQUENCY 100 Hz
MODE→MODU
FUNCTION
MODE → MODU,
TYPE=FM
DEVIATION 1000 Hz
MODE → MODU,
TYPE=AM
DEPTH 50 %
MODE → MODU,
TYPE=OFSM
DEVIATION 0.2 V
MODE → MODU,
TYPE=PM
DEVIATION 90 deg
MODE → MODU,
TYPE=PWM
DEVIATION 20 %
ENTRY→FREQ 1000 Hz
ENTRY→AMPTD 0.1 Vp-p
ENTRY→OFFSET 0 V
ENTRY→PHASE 0 deg
ENTRY→WIDTH 0.0005 s In case of FUNCTION=
ENTRY→DUTY 50 % In case of FUNCTION=
ENTRY→PERIOD 0.001 s
ENTRY→HIGH 0.05 V
ENTRY→LOW −0.05 V
FUNCTION
RANGE AUTO
LOAD OPEN (50 ohms at SET)
EXT-AM OFF
EXT-ADD OFF
DUTY-VALID IMMED
SYSTEM
SYNC-OUT STATE
