8-10 WF1945B
8.4 Initialized settings
z Initialized settings
Initialization,
“3.3 Basic operation (Initalization table)”, cf.
z Error from backup battery depletion
In addition to setting initialization, following are set:
Output on/off Off
Output on/off in turning on LAST-STATE (condition just before power off)
Setting memory
Setting memory comment
ALL NOT STORED
" " (blank)
User unit name USER
User unit computation formula (h+n)*m
User unit coefficient 1
User unit offset
Arbitrary waveform selection
0
ARB_00
Arbitrary waveform name
Arbitrary waveform data size
ARB_00
~ ARB_11
8K
Arbitrary waveform data
Remote control interface
All 0
GPIB
GPIB address 2
GPIB delimiter CR+LF
USB ID 2
