6.1 Error message
WF1945B 6-3
Operation error
Error message Cause or corrective measures
DATA OUT OF RANGE
Input values outside of permissible setting range.
Confirm permissible setting range and again input.
Upper and lower limits can be easily checked by using the
MODIFY dial to change the values.
INVALID NUMERIC DATA
Keypad input data invalid (e.g., decimal point only).
SETTINGS CONFLICT 001
Start or stop value set to 0 during LOG sweep and sweep cannot
be executed.
SETTINGS CONFLICT 002
Combined center and span exceed the permissible sweep type
(e.g., frequency) setting range.
SETTINGS CONFLICT 003
Combined modulation type (e.g., frequency) and Deviation or
DEPTH exceed the permissible modulation type setting range and
modulation cannot be executed.
SETTINGS CONFLICT 004
Combined modulation type (e.g., frequency) and Deviation or
DEPTH exceed the permissible modulation type setting range.
SETTINGS CONFLICT 007
Combined period and pulse width exceed the permissible duty
setting range.
SETTINGS CONFLICT 010
Since the mode is SWEEP or MODU for
(variable duty),
DUTY VALID cannot be set.
STORE/RECALL MEMORY
LOST
Setting storage memory contents destroyed and settings cannot be
recalled.
Contact dealer.
