6.1 Error messag
6-4 WF1945B
continued from previous page
Error message Cause or corrective measures
WARNING 001
Combined frequency and duty set the pulse width to not more than
25 ns and the pulse may be lost.
WARNING 002
Combined frequency and duty set the pulse width to 25 and 100 ns
and pulse width may be unstable (large jitter component).
WARNING 003
Since high frequency, burst oscillation mark and space may be
unstable.
WARNING 004
Low level setting changed due to high level setting change, or
conversely, high level setting changed due to low level setting
change.
WARNING 005
Changed to simple standard units (Hz, s, Vp-p, V).
WARNING 006
Since combined period and pulse width exceed the permissible
duty setting range, pulse width was changed in order to enter the
permissible duty range.
WARNING 015
Because of DUTY VALID change, the duty was changed to
0.01% or 99.99%.
WARNING 016
Because of a mode change, DUTY VALID was changed to
IMMED.
