NF WF1945B - Operation Tree; Output On;Off

3.3 Basic operation
WF1945B
3-28
 Operation tree
OUTPUT
ON/OFF
Output on/off
MODE
Oscillation mode
NORMAL
/
BURST
/
SWEEP
/
MODU
/
NOISE
/
DC
BURST
Menu
TYPE (Burst type) [BURST/TRIG/GATE/T-GATE]
SOURCE (Trigger/gate source selection)
DELAY (Trigger delay) * For TYPE: TRIG
MARK (Number of cycles signal present) * For TYPE: BURST/TRIG
SPACE (Number of cycles signal not present) * For TYPE: BURST
STOP-LEVEL (Stop level)
* When the same TYPE is set for both channels
BURST
Operation
MAN TRIG
