NF WF1945B - Burst Oscillation (Type: Burst)

4.1 Burst oscillation
WF1945B 4-3
(2) Set MARK cycle
① Use the
and keys to produce the following display (MARK flashes).
１．０ ｃｙｃｌｅ
ＢＵＲＳＴ：ＴＹＰＥ ＭＡＲＫ ＳＰＡＣＥ ＳＴＯＰ―ＬＥＶＥＬ
② Press the
ENTER
key.
③ Set the mark cycles with the keypad or
MODIFY
dial (0.5 cycles).
In this example, the setting is 2.0 cycles.
④ After setting, press the
EXIT
key once to exit mark cycle setting.
(3) Set SPACE cycle
① Use the
and keys to produce the following display (SPACE flashes)
１．０ ｃｙｃｌｅ
ＢＵＲＳＴ：ＴＹＰＥ ＭＡＲＫ ＳＰＡＣＥ ＳＴＯＰ―ＬＥＶＥＬ
② Press the
ENTER
key.
③ Set the space cycles with the keypad or
MODIFY
dial (0.5 cycles). In this example, the setting
is 1.5 cycles.
④ After setting, press
EXIT
once to exit space cycle setting.
(4) Set STOP-LEVEL
① Use the
and keys to produce the following display (STOP-LEVEL flashes).
ＯＦＦ
ＢＵＲＳＴ：ＴＹＰＥ ＭＡＲＫ ＳＰＡＣＥ ＳＴＯＰ―ＬＥＶＥＬ
