NF WF1945B - Rear Panel

3.1 Panel description
3-4 WF1945B
 Rear panel
Fuse holder (page 2-5)
GPIB connecto
r
Inspection label Nameplate Fan exhaust
Sync transfer input (1991 option, page 3-12) Sync transfer output (1991 option, page 3-12) Digital output (1992A option, page 3-14)
Sweep stop/restart input (page 3-10)
Sweep X-drive output (page 3-10)
External add input (page 3-11)
Sweep marker output (page 3-11)
External AM input (page 3-12)
Power supply input (page 2-5)
