3.2 Input and output connections
WF1945B 3-13
Note the following for synchronous operation of multiple products:
・Switch off all products before connecting or disconnecting sync transfer cables.
・Switch on all products that are connected by the sync transfer cables and that will be
used. Disconnect the sync transfer cable from any product that will not be used.
・If possible, simultaneously switch on all products that are connected by the sync transfer
cables.
If simultaneous switch-on is not possible, switch on products in succession from the
master (primary) side to the slave (secondary, tertiary) side.
・If possible, simultaneously switch off all products that are connected by the sync transfer
cables.
If simultaneous switch-off is not possible, switch off products in succession from the slave
(secondary, tertiary) side to the master (primary) side.
! CAUTION
