4.1 Burst oscillation
4-12 WF1945B
• Stop level off : Oscillation stops at the half-cycle after gate signal off (i.e., at the phase set by
ENTRY
→
PHASE
).
• Manual gate signal : Press the
MAN TRIG
key. The gate signal is on (i.e., oscillation) while the key
is pressed. In this case, set the trigger source for EXT L-ON.
• To generate the trigger signal via remote control (GPIB or USB), set the GET command or TRG
command from the remote control interface.
Also, set the trigger source to EXT L-ON.
For details of the remote control command,
“Remote Control Instruction Manual”, cf.
• Burst oscillation (type: gate) setting items (BURST menu)
TYPE: GATE
SOURCE (trigger source) [EXT L-ON, EXT H-ON, INT [s]
STOP-LEVEL [OFF, ON [%]]
PHASE (phase when oscillation starts) [deg] * ENTRY menu
