Introduction
This user manual describes the TemBreak PRO B Model Basic Electronic (B_BE) MCCB’s MCCB features and instructions for use, and provides
information for commissioning and configuring.
Some additional features may require the use of additional products and accessories to achieve full utilization of that feature. Refer the respective User
Manual in the TemBreak PRO series for additional information on the respective product.
Who Should Use This Manual?
This manual aims to provide users, electricians, panel builders and maintenance personnel, with the technical information required for commissioning and
operation of the NHP / Terasaki TemBreak PRO B_BE MCCB.
Users of this document must have at minimum a basic understanding of electrical circuit protection topics including (but not limited to):
- Power distribution and reticulation
- Circuit protection devices
- Fault currents
- Arc faults
- Temperature rise and thermal derating of switchgear
Additional resources
The following resources contain additional information which should be read in conjunction with this document.
Resource
Description
NHP/Terasaki TemBreak PRO B_BE Installation
Instructions
B250_3_BE-IN-001-EN
B250_4_BE-IN-001-EN
B400_3_BE-IN-001-EN
B400_4_BE-IN-001-EN
B800_3_BE-IN-001-EN
B800_4_BE-IN-001-EN
B1000_3_BE-IN-001-EN
B1000_4_BE-IN-001-EN
B1250_3_BE-IN-001-EN
B1250_4_BE-IN-001-EN
B1600_3_BE-IN-001-EN
B1600_4_BE-IN-001-EN
Information on installing, mounting, and wiring the TemBreak PRO B Model Basic
Electronic MCCB.
COMING SOON
Technical Data – Temperature and Watts Loss
TBP-TD-001-EN
Temperature and Watts Loss tables for TemBreak PRO Moulded Case Circuit Breakers.
Technical Data – Cascading and Selectivity
TBP-TD-002-EN
Cascading and Selectivity tables for TemBreak PRO Moulded Case Circuit Breakers with
Din-T, Din-Safe, & MOD6 MCBs/RCBOs
Technical Data – Coordination
TBP-TD-003-EN
Socomec Backup Tables with TemBreak PRO Moulded Case Circuit Breakers
Technical Data – Type 2 Coordination
Type2_TBpro_MotorStartTables-TD-001-EN
Type 2 Coordination for Premium Efficiency Motor Starters with TemBreak PRO Moulded
Case Circuit Breakers
Notice: Not all MCCBs in the TemBreak PRO series are identical. This document specifically covers the B_BE
series MCCB only. Refer to the respective TemBreak PRO User Manual (e.g. B_SE, P_SE, etc.) for information
and instructions on other models in the TemBreak PRO range.
