NHP TemBreak PRO - Part Number Break Down

Product Information
8
TemBreak PRO B_BE-UM-001-EN  V1.1.0
Part Number Break Down
P
160
F
2
4
160
BE
G
a)
b)
c)
d)
e)
f)
g)
h)
a) Model Type
A
Basic applications
(160…250 A)
P
Mid to advanced applications
(160…630 A)
B
High current, high kA applications
(160…1600 A)
ZS
Earth Leakage applications
(125…800 A)
XS
Highest current applications
(2000…3200 A)
b) Ampere Frame
125
A
160
A
250
A
400
A
630
A
800
A
1000
A
1250
A
1600
A
2000
A
2500
A
3200
A
c) Short Circuit Break Capacity I
cu
(kA)
R
200 kA
L
150 kA
P
125 kA
S
110 kA
G
100 kA
HL
85 kA
H
70 kA
M
65 kA
N
50 kA
F
36 kA
E
25 kA
D
Switch
d) Pole Pitch Size (mm)
1)
1
25
2
30
3
35
e) No. of Poles
1
6)
2
7)
3
4
f) Trip Unit Rating (I
n
)
I
n
x A
g) Trip Unit Type
TF
Adj Thermal Fix Magnetic
3)
FF
Fix Thermal Fix Magnetic
3)
FM
Fix Thermal Adj Magnetic
8)
TM
Adj Thermal Adj Magnetic
SX
Smart Ammeter
4) 5)
BE
Basic Electronic
5)
SE
Smart Energy
5)
NN
Non-Auto Switch
h) Trip Unit Option
G
Ground Fault
2)
N
Neutral
2)
P
Pre-Trip Alarm
2)
SN
Solid Neutral
8)
1. 160AF only
2. For P_SE versions these features are standard and therefore are not added to the end of the part number.
3. Only available in A & ZS models
4. Only available in B models
5. Not available in A models
6. Only available in A and B models (FF Only Trip Unit)
7. Not available in A and B models (FF Only Trip Unit)
8. ZS Models
Notice: Not all combinations are possible. Confirm part number combination with NHP for availability.
