Nice Apollo 1724 - 12 Board Nomenclature

20
12 - BOARD NOMENCLATURE
Not Used
Function select
Display select
Spare fuses
Incoming 30
Amp fuse
Reset and hard
shut down
button
LCD screen
OK or accept
Selection down
Selection up
Open the gate
Stop gate
movement
Close the gate
Force select
Speed select
Delay select
Battery Input
Battery Charger
Input
GENERAL BOARD OVERVIEW
THE PROGRAMMING BUTTONS INDICATED IN THE ABOVE REFERENCE SHOULD BE USED ONLY AFTER UNDERSTANDING THE
MANUAL AND ITS RELATION TO THE PROGRAMMING SEQUENCES SHOWN ON THE FOLLOWING PAGES. CARE SHOULD BE TAKEN
WHENEVER CHANGES ARE IMPLEMENTED TO ENSURE PROPER FUNCTIONALITY AND SAFETY.
