22
be assigned to any combination of days of the week (Monday through
Sunday). Events that are already programmed into the system may be
suspended temporarily, or removed permanently from memory. The following
actions can be assigned to events:
• Select Master / Slave Motor1 or Motor2
• Activate link for remote Master/Slave (Enables control of an additional gate
operator board)
• Power Fail Open (Opens gate automatically on batter backup power if main
AC power input loss is detected) not applicable in this system
• Motor 12V (Forces motor control voltage to +12VDC even if the supply
voltage varies from +9.5VDC up to +35VDC)
Default: This setting gives the installer/user the option of returning some or
all settings of the gate operator to the original factory settings:
• System settings
• Radio Channel settings
• Event settings
• Charger settings
ESC: Exit the FUNCTION menu.
13.6 Display
ESC: Exit the DISPLAY menu.
Info: Displays the manufacturer name, product name/model, software
versions, and serial number.
Clock: Displays the calendar date and time in the real time clock. Pressing
and holding the “OK” button for 5 seconds enables the date and time
settings to be updated manually.
Main Volt: Displays the gate operator main control voltage in volts DC.
Battery Volt: Displays the gate operator backup battery voltage in volts DC.
Sun Volt: Displays the solar panel input voltage in volts DC.
Motor Volt: Displays the voltage at the motor in volts DC.
UL Volt: Displays the voltage at the UL/Edge sensor input in volts DC.
Temperature: Displays the temperature of the gate controller board in
degrees Centigrade or Fahrenheit (press OK and hold 5 seconds to change
scale).
Service: The following information is recorded and viewable about the
operating history of the gate:
• Total: Displays the total number of open close cycles (non Settings ).
• Partial: Display the total number of partial cycles. Reset by pressing the
“OK” button for several seconds.
• Maint. Display the number of cycles before service is required. Settings
from 1000 to 50000 cycles in increments of 1000 cycles.
Motor: Displays the Motor position, voltage, and current.
Motor 1: Displays the Motor1 position, voltage, and current.
Motor 2: Displays the Motor2 position, voltage, and current.
Charger: Displays the battery charger voltage and current.
Last Reset: Displays the code for diagnostic review. Used for diagnostic and
troubleshooting.
ESC: Exit the DISPLAY menu.
• No program
• Open
• Close
• Partial
• Partial1
• AxOut1On
• AxOut1 Off
• AxOut2 On
• AxOut2 Off
• Open and LOCK
• Close and LOCK
• Open and UNLOCK
• Close and UNLOCK
To program weekly events EV1 through EV8, perform the following
steps:
1. Press FUNCTION > Events.
2. Press and hold OK to display EV1 (display will blink “EV1”).
3. Press UP or DOWN to toggle between events, then press OK to make a
selection. The display changes to hours.
4. Press UP or DOWN to toggle between hours, then press OK to make a
selection. The display changes to minutes.
5. Press UP or DOWN to toggle between minutes, then press OK to make a
selection. The display changes to individual days of the week.
6. Press UP or DOWN to toggle between days of the week. Press OK to
toggle between ON and OFF for each day of the week. Continue toggling
through the days of the week until ESC is displayed. Press OK to advance
to the next event.
7. Repeat step 2 through 6 for event EV2 through EV8.
To temporarily suspend one or more weekly events (EV1 through
EV8), perform the following steps:
1. Press FUNCTION > Events.
2. Press OK quickly to display EV1 active days.
3. Press OK quickly again to display “Suspend”. Event EV1 is now
suspended and will not run until re enabled.
4. Press UP or DOWN to toggle through the events EV1 – EV8 and repeat
steps 2 through 3 to suspend or enable other weekly events.
Charger: A battery charger is built in with the Control board to keep battery
charged. Keep this setting at the system default to properly keep batteries
charged.
Standby: Programs the timeout for the gate operator to go into low power
standby mode. Low power standby is Settings from 5 to 120 seconds, or
may be disabled with “OFF”. During low power standby there is no data
displayed on the gate operator LCD and it consumes a minimum amount of
power to extend the life of the backup battery. All the outputs are switched
off and the LED OK blinks to show this standby status of the system.
Advance Settings: The following settings are available for customizing the
gate operator as required by the customer’s installation requirements:
• Set Language (English Spanish French)
• Set clock 12H/24H
• Set LCD Contrast
• Set Virtual Encoder (Used for motors without built in encoders)
• Set Anti tailgate (Closes gate immediately after vehicle has cleared safety
sensors)
• Select inputs LOOP or PHOTO
• Select UL/EDGE input type (NO, NC, Analog)
To Next Page
