5 - CONTROL BOX LAYOUT
Transformer
Battery
Motor 1
Connection
Motor 2
Connection
Connection Not Used
Connection
Internal Door Closed
Main power switch
Power Supply 12VDC Batteries
Line
Fuse
120VAC Input connection Siren
Internal Door Open
