AFFIX GATE BRACKET TO ACTUATOR ARM
3
1/2”x 2” PIVOT BOLT
1/2”x 2” PIVOT BOLT
GATE BRACKET
(SIDE VIEW)
GATE BRACKET
ACTUATOR
ARM
1/2” LOCK NUT
WASHER (ZINC)
ACTUATOR
ARM
FIG-3A: AFFIXING GATE BRACKET TO ACTUATOR ARM
FIG-3B: GATE BRACKET HARDWARE REQUIREMENTS
WASHER
WASHER
(STAINLESS STEEL)
LOCK NUT
If the gate bracket is not already installed on the actuator arm, mount gate bracket to actuator arm with the
pivot bolt, nut, and washers per images below.
WASHER
