5. Descriptions of CN1 Connector Signals
Pin No.
11
Interface Circuit
PI（page 45） Control Mode
Signal Description P S T
TLSEL1
Torque Limit
Open
Torque command limit: Value 1 (No.147.0) is applied.
Close
Torque command limit: Value 2 (No.148.0) is applied.
■ Related Parameters
･No.144.0
Torque Limit is enabled when 1 (enable) is selected.
･No.147.0, No.148.0
Set Torque Command Limit Values 1 and 2.
dif.
24
5
i/o
䐟
䐠
䐡
䐢
**
v
ol
t
i/o
䐟
䐠
䐡
v
ol
t
ORG
Home Sensor
Open
Home sensor has not been detected.
Close
Home sensor has been detected.
■ Related Parameters
･No.645.0
Enables you to select home-sensor-front.
･No.646.1
Enables you to change the polarity of home sensor detection.
i/o
䐟
䐠
䐡
䐢
*
* In Standard I/O conguration
** In Optional I/O conguration.
