Nikon D5200 User Manual

36
AF-Area Mode
Choose how the focus point for autofocus is selected. Note that d (dynamic-area)
and f (3D-tracking) AF-area modes are not available when AF-S is selected for focus
mode.
1 Place the cursor in the information display.
If shooting information is not displayed in
the monitor, press the P button.
Press the
P button again to place the cursor in the
information display.
2 Display AF-area mode options.
Highlight the current AF-area mode in the
information display and press J.
Option Description
c Single-point AF
User selects focus point using multi selector (0 38); camera focuses
on subject in selected focus point only. Use with stationary
subjects.
J
Dynamic-area AF
(9 points)
In AF-A and AF-C focus modes, user selects focus point using multi
selector (0 38), but camera will focus based on information from
surrounding focus points if subject briefly leaves selected point.
The number of focus points varies with the mode selected:
• 9-point dynamic-area AF: Choose when there is time to compose the
photograph or when photographing subjects that are moving
predictably (e.g., runners or race cars on a track).
• 21-point dynamic-area AF: Choose when photographing subjects that
are moving unpredictably (e.g., players at a football game).
• 39-point dynamic-area AF: Choose when photographing subjects that
are moving quickly and can not be easily framed in the viewfinder
(e.g., birds).
K
Dynamic-area AF
(21 points)
L
Dynamic-area AF
(39 points)
f 3D-tracking
In AF-A and AF-C focus modes, user selects focus point using multi
selector (0 38). If subject moves after camera has focused, camera
uses 3D-tracking to select new focus point and keep focus locked on
original subject while shutter-release button is pressed halfway. Use
to quickly compose pictures with subjects that are moving
erratically from side to side (e.g., tennis players). If subject leaves
viewfinder, remove your finger from shutter-release button and
recompose photograph with subject in selected focus point.
e Auto-area AF Camera automatically detects subject and selects focus point.
P button Information display

Nikon D5200 Specifications

General

Megapixel	24.1 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Image stabilizer	No
Total megapixels	24.71 MP
Image sensor size	- \
Maximum image resolution	6000 x 4000 pixels
Image sensor size (W x H)	23.5 x 15.6 mm
Still image resolution(s)	6000 x 4000
Optical zoom	- x
Focal length range	- mm
Lens mount interface	Nikon F
Minimum aperture number	-
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) lock	Yes
Auto Focus (AF) points	39
Auto focusing (AF) modes	Continuous Auto Focus, Servo Auto Focus, Single Auto Focus, Tracking Auto Focus
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 6400, 25600
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	100
Light exposure correction	± 5EV (1/3EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	30 s
Flash modes	Auto, Fill-in, Flash off, Red-eye reduction, Slow synchronization
Flash sync-speed	1/200 s
Power source type	Battery
Video resolutions	640 x 424, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	59.94 fps
Video formats supported	H.264, MOV, MPEG4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Audio formats supported	PCM
Internal memory	0 MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display resolution (numeric)	921000 pixels
Magnification	0.78 x
Viewfinder type	Optical
USB version	2.0
Product color	Bronze
Scene modes	Beach, Candlelight, Children, Close-up (macro), Dawn, Dusk, Night landscape, Night portrait, Party (indoor), Portrait, Self-portrait, Snow, Sports, Sunrise, Sunset, Landscape (scenery)
Photo effects	Neutral, Vivid
White balance	Auto, Cloudy, Fluorescent, Incandescent, Manual, Shade, Sunny
Shooting modes	Aperture priority, Auto, Manual, Movie, Program, Scene, Shutter priority
Camera playback	Highlights, Movie, Single image, Slide show, Thumbnails
Self-timer delay	2, 5, 10, 20 s
Camera file system	DCF 2.0, DPOF 1.1, Exif 2.3
On Screen Display (OSD) languages	ARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, KOR, NOR, POL, POR, RUM, RUS, SWE, THA, TUR, UKR
Battery type	EN-EL14
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 85 %
Cables included	AV, USB

Weight and Dimensions

Depth	78 mm
Width	129 mm
Height	98 mm
Weight	555 g
