Nikon D5200 User Manual

201
Compatible Non-CPU Lenses
Non-CPU lenses may only be used when the camera is in mode M. Selecting another
mode disables the shutter release.
Aperture must be adjusted manually via the lens
aperture ring and the camera metering system, i-TTL flash control, and other features
requiring a CPU lens can not be used.
Some non-CPU lenses can not be used; see
“Incompatible Accessories and Non-CPU Lenses,” below.
Camera setting Focus Mode Metering
Lens/accessory AF
MF (with electronic
rangefinder)
MF M Other modes L, M, N
AI-, AI-modified NIKKOR or Nikon Series E lenses — z
1
zz
2
——
Medical NIKKOR 120mm f/4 — zzz
2, 3
——
Reflex NIKKOR — — zz
2
——
PC NIKKOR — z
4
zz
2
——
AI-type Teleconverter — z
5
zz
2
——
PB-6 Bellows Focusing Attachment
6
— z
1
zz
2
——
Auto extension rings (PK-series 11A, 12, or 13;
PN-11)
— z
1
zz
2
——
1 With maximum aperture of f/5.6 or faster.
2 Exposure indicator can not be used.
3 Can be used at shutter speeds slower than flash sync speed by one step or more.
4 Can not be used with shifting or tilting.
5 With maximum effective aperture of f/5.6 or faster.
6 Attach in vertical orientation (can be used in horizontal orientation once attached).
D Incompatible Accessories and Non-CPU Lenses
The following accessories and non-CPU lenses can NOT be used with the D5200:
• TC-16AS AF teleconverter
• Non-AI lenses
• Lenses that require the AU-1 focusing unit (400mm f/4.5, 600mm f/5.6, 800mm f/8,
1200mm f/11)
• Fisheye (6mm f/5.6, 7.5mm f/5.6, 8mm f/8, OP 10mm f/5.6)
• 2.1cm f/4
• Extension Ring K2
• 180–600mm f/8 ED (serial numbers 174041–174180)
• 360–1200mm f/11 ED (serial numbers 174031–174127)
• 200–600mm f/9.5 (serial numbers 280001–300490)
• AF lenses for the F3AF (AF 80mm f/2.8, AF 200mm f/3.5 ED, AF Teleconverter TC-16)
• PC 28mm f/4 (serial number 180900 or earlier)
• PC 35mm f/2.8 (serial numbers 851001–906200)
• PC 35mm f/3.5 (old type)
• Reflex 1000mm f/6.3 (old type)
• Reflex 1000mm f/11 (serial numbers 142361–143000)
• Reflex 2000mm f/11 (serial numbers 200111–200310)

Nikon D5200 Specifications

General

Megapixel	24.1 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Image stabilizer	No
Total megapixels	24.71 MP
Image sensor size	- \
Maximum image resolution	6000 x 4000 pixels
Image sensor size (W x H)	23.5 x 15.6 mm
Still image resolution(s)	6000 x 4000
Optical zoom	- x
Focal length range	- mm
Lens mount interface	Nikon F
Minimum aperture number	-
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) lock	Yes
Auto Focus (AF) points	39
Auto focusing (AF) modes	Continuous Auto Focus, Servo Auto Focus, Single Auto Focus, Tracking Auto Focus
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 6400, 25600
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	100
Light exposure correction	± 5EV (1/3EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	30 s
Flash modes	Auto, Fill-in, Flash off, Red-eye reduction, Slow synchronization
Flash sync-speed	1/200 s
Power source type	Battery
Video resolutions	640 x 424, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	59.94 fps
Video formats supported	H.264, MOV, MPEG4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Audio formats supported	PCM
Internal memory	0 MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display resolution (numeric)	921000 pixels
Magnification	0.78 x
Viewfinder type	Optical
USB version	2.0
Product color	Bronze
Scene modes	Beach, Candlelight, Children, Close-up (macro), Dawn, Dusk, Night landscape, Night portrait, Party (indoor), Portrait, Self-portrait, Snow, Sports, Sunrise, Sunset, Landscape (scenery)
Photo effects	Neutral, Vivid
White balance	Auto, Cloudy, Fluorescent, Incandescent, Manual, Shade, Sunny
Shooting modes	Aperture priority, Auto, Manual, Movie, Program, Scene, Shutter priority
Camera playback	Highlights, Movie, Single image, Slide show, Thumbnails
Self-timer delay	2, 5, 10, 20 s
Camera file system	DCF 2.0, DPOF 1.1, Exif 2.3
On Screen Display (OSD) languages	ARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, KOR, NOR, POL, POR, RUM, RUS, SWE, THA, TUR, UKR
Battery type	EN-EL14
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 85 %
Cables included	AV, USB

Weight and Dimensions

Depth	78 mm
Width	129 mm
Height	98 mm
Weight	555 g
