Nikon D5200 User Manual

171
If On is selected, the information display will appear after the shutter-release button
is pressed halfway; if image review (0 149) is off, it will also be displayed immediately
after shooting.
Choose On if you find yourself frequently referring to the information
display during shooting.
If Off is selected, the information display can be viewed by
pressing the P button.
Acquire reference data for the Image Dust Off option in Capture NX 2 (available
separately; for more information, see the Capture NX 2 manual).
Image Dust Off ref photo is available only when a CPU lens is mounted on the
camera.
A lens with a focal length of at least 50 mm is recommended. When using a
zoom lens, zoom all the way in.
1 Choose a start option.
Highlight one of the following options and press
J.
To exit without acquiring image dust off
data, press G.
• Start: The message shown at right will be
displayed and “rEF” will appear in the
viewfinder.
• Clean sensor and then start: Select this option to
clean the image sensor before starting.
The
message shown at right will be displayed and
“rEF” will appear in the viewfinder when
cleaning is complete.
2 Frame a featureless white object in the viewfinder.
With the lens about ten centimeters (four inches) from a well-lit, featureless
white object, frame the object so that it fills the viewfinder and then press the
shutter-release button halfway.
In autofocus mode, focus will automatically be set to infinity; in manual focus
mode, set focus to infinity manually.
Auto Info Display
G button ➜ B setup menu
Image Dust Off Ref Photo
G button ➜ B setup menu
D Image Sensor Cleaning
Image Dust Off reference data recorded before image sensor cleaning is performed
can not be used with photographs taken after image sensor cleaning is performed.
Select Clean sensor and then start only if the Image Dust Off reference data will not
be used with existing photographs.

Nikon D5200 Specifications

General

Megapixel	24.1 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Image stabilizer	No
Total megapixels	24.71 MP
Image sensor size	- \
Maximum image resolution	6000 x 4000 pixels
Image sensor size (W x H)	23.5 x 15.6 mm
Still image resolution(s)	6000 x 4000
Optical zoom	- x
Focal length range	- mm
Lens mount interface	Nikon F
Minimum aperture number	-
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) lock	Yes
Auto Focus (AF) points	39
Auto focusing (AF) modes	Continuous Auto Focus, Servo Auto Focus, Single Auto Focus, Tracking Auto Focus
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 6400, 25600
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	100
Light exposure correction	± 5EV (1/3EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	30 s
Flash modes	Auto, Fill-in, Flash off, Red-eye reduction, Slow synchronization
Flash sync-speed	1/200 s
Power source type	Battery
Video resolutions	640 x 424, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	59.94 fps
Video formats supported	H.264, MOV, MPEG4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Audio formats supported	PCM
Internal memory	0 MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display resolution (numeric)	921000 pixels
Magnification	0.78 x
Viewfinder type	Optical
USB version	2.0
Product color	Bronze
Scene modes	Beach, Candlelight, Children, Close-up (macro), Dawn, Dusk, Night landscape, Night portrait, Party (indoor), Portrait, Self-portrait, Snow, Sports, Sunrise, Sunset, Landscape (scenery)
Photo effects	Neutral, Vivid
White balance	Auto, Cloudy, Fluorescent, Incandescent, Manual, Shade, Sunny
Shooting modes	Aperture priority, Auto, Manual, Movie, Program, Scene, Shutter priority
Camera playback	Highlights, Movie, Single image, Slide show, Thumbnails
Self-timer delay	2, 5, 10, 20 s
Camera file system	DCF 2.0, DPOF 1.1, Exif 2.3
On Screen Display (OSD) languages	ARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, KOR, NOR, POL, POR, RUM, RUS, SWE, THA, TUR, UKR
Battery type	EN-EL14
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 85 %
Cables included	AV, USB

Weight and Dimensions

Depth	78 mm
Width	129 mm
Height	98 mm
Weight	555 g
