Nikon D5200 User Manual

175
Choose the role of the optional accessory connected to the accessory terminal.
❚❚ Remote Shutter Release
If Remote shutter release is selected, you can choose whether the shutter-release
button on optional accessory is used for photography or movie recording.
Remote
shutter release is available when an optional WR-R10 wireless remote controller is
connected to the camera and used with the shutter-release button on a WR-T10
wireless remote controller.
Remote shutter release is also available with optional
MC-DC2 remote cords (0 210).
❚❚ GPS
This item is used to adjust settings for optional GPS units (0 210). A GPS unit can be
connected to the camera’s accessory terminal (0 210) using the cable supplied with
the unit, allowing information on the camera’s current position to be recorded when
photographs are taken (turn the camera off before connecting the GPS unit; for more
information, see the GPS unit manual).
The GPS menu contains the options listed below.
• Standby timer: Choose whether the exposure meters turn off automatically when the
a GPS unit is attached.
• Position: This item is only available if a GPS unit is connected, when it displays the
current latitude, longitude, altitude, and Coordinated Universal Time (UTC) as
reported by GPS.
• Use GPS to set camera clock: Select Ye s to synchronize the camera clock with the time
reported by the GPS device.
Accessory Terminal
G button ➜ B setup menu
Option Description
y Take photos
The shutter-release button on the optional accessory is used to take
photographs.
z Record movies
The shutter-release button on the optional accessory is used for movie
recording. Press the button halfway to start live view or to focus in AF-S
and AF-F modes. Press the button all the way down to start or end
recording. Use the live view switch to end live view.
Option Description
Enable
Exposure meters turn off automatically if no operations are performed for the
time selected for Custom Setting c2 (Auto off timers > Standby timer, 0 160 to
allow the camera time to acquire GPS data, the delay is extended by up to one
minute after exposure meters are activated or the camera is turned on). This
reduces the drain on the battery.
Disable Exposure meters do not turn off while a GPS unit is connected.
A Coordinated Universal Time (UTC)
UTC data is provided by the GPS device and is independent of the camera clock.

Nikon D5200 Specifications

General

Megapixel	24.1 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Image stabilizer	No
Total megapixels	24.71 MP
Image sensor size	- \
Maximum image resolution	6000 x 4000 pixels
Image sensor size (W x H)	23.5 x 15.6 mm
Still image resolution(s)	6000 x 4000
Optical zoom	- x
Focal length range	- mm
Lens mount interface	Nikon F
Minimum aperture number	-
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) lock	Yes
Auto Focus (AF) points	39
Auto focusing (AF) modes	Continuous Auto Focus, Servo Auto Focus, Single Auto Focus, Tracking Auto Focus
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 6400, 25600
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	100
Light exposure correction	± 5EV (1/3EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	30 s
Flash modes	Auto, Fill-in, Flash off, Red-eye reduction, Slow synchronization
Flash sync-speed	1/200 s
Power source type	Battery
Video resolutions	640 x 424, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	59.94 fps
Video formats supported	H.264, MOV, MPEG4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Audio formats supported	PCM
Internal memory	0 MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display resolution (numeric)	921000 pixels
Magnification	0.78 x
Viewfinder type	Optical
USB version	2.0
Product color	Bronze
Scene modes	Beach, Candlelight, Children, Close-up (macro), Dawn, Dusk, Night landscape, Night portrait, Party (indoor), Portrait, Self-portrait, Snow, Sports, Sunrise, Sunset, Landscape (scenery)
Photo effects	Neutral, Vivid
White balance	Auto, Cloudy, Fluorescent, Incandescent, Manual, Shade, Sunny
Shooting modes	Aperture priority, Auto, Manual, Movie, Program, Scene, Shutter priority
Camera playback	Highlights, Movie, Single image, Slide show, Thumbnails
Self-timer delay	2, 5, 10, 20 s
Camera file system	DCF 2.0, DPOF 1.1, Exif 2.3
On Screen Display (OSD) languages	ARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, KOR, NOR, POL, POR, RUM, RUS, SWE, THA, TUR, UKR
Battery type	EN-EL14
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 85 %
Cables included	AV, USB

Weight and Dimensions

Depth	78 mm
Width	129 mm
Height	98 mm
Weight	555 g
