213
Caring for the Camera
Storage
When the camera will not be used for an extended period, remove the battery and
store it in a cool, dry area with the terminal cover in place.
To prevent mold or
mildew, store the camera in a dry, well-ventilated area.
Do not store your camera
with naphtha or camphor moth balls or in locations that:
are poorly ventilated or subject to humidities of over 60%
are next to equipment that produces strong electromagnetic fields, such as
televisions or radios
are exposed to temperatures above 50 °C (122 °F) or below –10 °C (14 °F)
Cleaning
Do not use alcohol, thinner, or other volatile chemicals.
Camera
body
Use a blower to remove dust and lint, then wipe gently with a soft, dry cloth.
After
using the camera at the beach or seaside, wipe off sand or salt with a cloth lightly
dampened in distilled water and dry thoroughly.
Important: Dust or other foreign
matter inside the camera may cause damage not covered under warranty.
Lens,
mirror, and
viewfinder
These glass elements are easily damaged.
Remove dust and lint with a blower.
If
using an aerosol blower, keep the can vertical to prevent the discharge of liquid.
To
remove fingerprints and other stains, apply a small amount of lens cleaner to a soft
cloth and clean with care.
Monitor
Remove dust and lint with a blower.
When removing fingerprints and other stains,
wipe the surface lightly with a soft cloth or chamois leather.
Do not apply pressure,
as this could result in damage or malfunction.
D Servicing the Camera and Accessories
The camera is a precision device and requires regular servicing.
Nikon recommends that the
camera be inspected by the original retailer or Nikon-authorized service representative once
every one to two years, and that it be serviced once every three to five years (note that fees
apply to these services).
Frequent inspection and servicing are particularly recommended if
the camera is used professionally.
Any accessories regularly used with the camera, such as
lenses or optional flash units, should be included when the camera is inspected or serviced.

Table of Contents

Other manuals for Nikon D5200

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Nikon D5200 and is the answer not in the manual?

Nikon D5200 Specifications

General IconGeneral
Megapixel24.1 MP
Camera typeSLR Camera Body
Sensor typeCMOS
Image stabilizerNo
Total megapixels24.71 MP
Image sensor size- \
Maximum image resolution6000 x 4000 pixels
Image sensor size (W x H)23.5 x 15.6 mm
Still image resolution(s)6000 x 4000
Optical zoom- x
Focal length range- mm
Lens mount interfaceNikon F
Minimum aperture number-
FocusTTL
Focus adjustmentAuto/Manual
Auto Focus (AF) lockYes
Auto Focus (AF) points39
Auto focusing (AF) modesContinuous Auto Focus, Servo Auto Focus, Single Auto Focus, Tracking Auto Focus
Light meteringCentre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity100, 6400, 25600
Light exposure modesAperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)25600
ISO sensitivity (min)100
Light exposure correction± 5EV (1/3EV step)
Camera shutter typeElectronic
Fastest camera shutter speed1/4000 s
Slowest camera shutter speed30 s
Flash modesAuto, Fill-in, Flash off, Red-eye reduction, Slow synchronization
Flash sync-speed1/200 s
Power source typeBattery
Video resolutions640 x 424, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate59.94 fps
Video formats supportedH.264, MOV, MPEG4
Maximum video resolution1920 x 1080 pixels
Analog signal format systemNTSC, PAL
Audio formats supportedPCM
Internal memory0 MB
Compatible memory cardsSD, SDHC, SDXC
Field of view100 %
Display diagonal3 \
Display resolution (numeric)921000 pixels
Magnification0.78 x
Viewfinder typeOptical
USB version2.0
Product colorBronze
Scene modesBeach, Candlelight, Children, Close-up (macro), Dawn, Dusk, Night landscape, Night portrait, Party (indoor), Portrait, Self-portrait, Snow, Sports, Sunrise, Sunset, Landscape (scenery)
Photo effectsNeutral, Vivid
White balanceAuto, Cloudy, Fluorescent, Incandescent, Manual, Shade, Sunny
Shooting modesAperture priority, Auto, Manual, Movie, Program, Scene, Shutter priority
Camera playbackHighlights, Movie, Single image, Slide show, Thumbnails
Self-timer delay2, 5, 10, 20 s
Camera file systemDCF 2.0, DPOF 1.1, Exif 2.3
On Screen Display (OSD) languagesARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, KOR, NOR, POL, POR, RUM, RUS, SWE, THA, TUR, UKR
Battery typeEN-EL14
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)0 - 85 %
Cables includedAV, USB
Weight and Dimensions IconWeight and Dimensions
Depth78 mm
Width129 mm
Height98 mm
Weight555 g
