Nikon D5200 User Manual

224
Troubleshooting
If the camera fails to function as expected, check the list of common problems below
before consulting your retailer or Nikon representative.
Battery/Display
Shooting (All Modes)
The camera is on but does not respond: Wait for recording to end. If the problem persists, turn the
camera off. If the camera does not turn off, remove and reinsert the battery or, if you are using
an AC adapter, disconnect and reconnect the AC adapter. Note that although any data
currently being recorded will be lost, data that have already been recorded will not be affected
by removing or disconnecting the power source.
Viewfinder is out of focus: Adjust viewfinder focus or use optional eyepiece correction lenses
(0 17, 209).
Displays turn off without warning: Choose longer delays for Custom Setting c2 (Auto off timers;
0 160).
Information display does not appear in monitor: Shutter-release button is pressed halfway.
If
information display does not appear when you remove your finger from shutter-release
button, confirm that On is selected for Auto info display (0 171) and that battery is charged.
Viewfinder display is unresponsive and dim: The response times and brightness of this display vary
with temperature.
Camera takes time to turn on: Delete files or folders.
Shutter-release disabled:
• Memory card is locked, full, or not inserted (0 15, 18, 20).
• Release locked is selected for Custom Setting f4 (Slot empty release lock; 0 166) and no
memory card is inserted (0 15).
• Built-in flash is charging (0 23).
• Camera is not in focus (0 22).
• CPU lens with aperture ring attached but aperture not locked at highest f-number (0 200).
• Non-CPU lens is attached but camera is not in mode M (0 201).
Only one shot taken each time shutter-release button is pressed in continuous shooting mode: Continuous
shooting is not available if built-in flash fires (0 30, 45).
Final photo is larger than area shown in viewfinder: Viewfinder horizontal and vertical frame coverage
is approximately 95%.
Photos are out of focus:
• AF-S or AF-I lens is not attached: use AF-S or AF-I lens or focus manually.
• Camera unable to focus using autofocus: use manual focus or focus lock (0 34, 38, 40).
• Camera is in manual focus mode: focus manually (0 40).

Nikon D5200 Specifications

General

Megapixel	24.1 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Image stabilizer	No
Total megapixels	24.71 MP
Image sensor size	- \
Maximum image resolution	6000 x 4000 pixels
Image sensor size (W x H)	23.5 x 15.6 mm
Still image resolution(s)	6000 x 4000
Optical zoom	- x
Focal length range	- mm
Lens mount interface	Nikon F
Minimum aperture number	-
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) lock	Yes
Auto Focus (AF) points	39
Auto focusing (AF) modes	Continuous Auto Focus, Servo Auto Focus, Single Auto Focus, Tracking Auto Focus
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 6400, 25600
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	100
Light exposure correction	± 5EV (1/3EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	30 s
Flash modes	Auto, Fill-in, Flash off, Red-eye reduction, Slow synchronization
Flash sync-speed	1/200 s
Power source type	Battery
Video resolutions	640 x 424, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	59.94 fps
Video formats supported	H.264, MOV, MPEG4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Audio formats supported	PCM
Internal memory	0 MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display resolution (numeric)	921000 pixels
Magnification	0.78 x
Viewfinder type	Optical
USB version	2.0
Product color	Bronze
Scene modes	Beach, Candlelight, Children, Close-up (macro), Dawn, Dusk, Night landscape, Night portrait, Party (indoor), Portrait, Self-portrait, Snow, Sports, Sunrise, Sunset, Landscape (scenery)
Photo effects	Neutral, Vivid
White balance	Auto, Cloudy, Fluorescent, Incandescent, Manual, Shade, Sunny
Shooting modes	Aperture priority, Auto, Manual, Movie, Program, Scene, Shutter priority
Camera playback	Highlights, Movie, Single image, Slide show, Thumbnails
Self-timer delay	2, 5, 10, 20 s
Camera file system	DCF 2.0, DPOF 1.1, Exif 2.3
On Screen Display (OSD) languages	ARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, KOR, NOR, POL, POR, RUM, RUS, SWE, THA, TUR, UKR
Battery type	EN-EL14
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 85 %
Cables included	AV, USB

Weight and Dimensions

Depth	78 mm
Width	129 mm
Height	98 mm
Weight	555 g
