Nikon D5200 User Manual

154
❚❚ Auto ISO Sensitivity control
If Off is chosen for Auto ISO sensitivity control in P, S, A, and M modes, ISO sensitivity
will remain fixed at the value selected by the user (0 49).
When On is chosen, ISO
sensitivity will automatically be adjusted if optimal exposure can not be achieved at
the value selected by the user (ISO sensitivity is adjusted appropriately when the
flash is used).
The maximum value for auto ISO sensitivity can be selected using the
Maximum sensitivity option in the Auto ISO sensitivity control menu (choose
lower values to prevent noise (randomly-spaced bright pixels, fog, or lines, but note
that if the ISO sensitivity selected by the user is higher than that chosen for
Maximum sensitivity, the value selected by the user will be used instead; the
minimum value for auto ISO sensitivity is automatically set to ISO 100)).
In modes P
and A, sensitivity will only be adjusted if underexposure would result at the shutter
speed selected for Minimum shutter speed (
1
/2000–1 s, or Auto; in modes S and M,
sensitivity will be adjusted for optimal exposure at the shutter speed selected by the
user).
If Auto (available only with CPU lenses) is selected, the camera will choose the
minimum shutter speed based on the focal length of the lens (auto shutter-speed
selection can be fine-tuned by highlighting Auto and pressing 2 ; for example, faster
values can be used with telephoto lenses to reduce blur).
Slower shutter speeds will
be used only if optimum exposure can not be achieved at the ISO sensitivity value
selected for Maximum sensitivity.
When On is selected, the viewfinder shows ISO-AUTO and the
information display ISO-A.
These indicators flash when
sensitivity is altered from the value selected by the user.
A Maximum Sensitivity/Minimum Shutter Speed
When auto ISO sensitivity control is enabled, the ISO sensitivity
and shutter speed graphics in the information display show the
maximum sensitivity and minimum shutter speed.
A Auto ISO Sensitivity Control
Noise (randomly-spaced bright pixels, fog, or lines) is more likely at higher sensitivities. Use
the High ISO NR option in the shooting menu to reduce noise (0 153). Note that ISO
sensitivity may be raised automatically when auto ISO sensitivity control is used in
combination with slow sync flash modes (available with the built-in flash and the optional
flash units listed on page 205), possibly preventing the camera from selecting slow shutter
speeds.
Mi
n
i
mum s
h
utter spee
d
Maximum sensitivit
y

Nikon D5200 Specifications

General

Megapixel	24.1 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Image stabilizer	No
Total megapixels	24.71 MP
Image sensor size	- \
Maximum image resolution	6000 x 4000 pixels
Image sensor size (W x H)	23.5 x 15.6 mm
Still image resolution(s)	6000 x 4000
Optical zoom	- x
Focal length range	- mm
Lens mount interface	Nikon F
Minimum aperture number	-
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) lock	Yes
Auto Focus (AF) points	39
Auto focusing (AF) modes	Continuous Auto Focus, Servo Auto Focus, Single Auto Focus, Tracking Auto Focus
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 6400, 25600
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	100
Light exposure correction	± 5EV (1/3EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	30 s
Flash modes	Auto, Fill-in, Flash off, Red-eye reduction, Slow synchronization
Flash sync-speed	1/200 s
Power source type	Battery
Video resolutions	640 x 424, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	59.94 fps
Video formats supported	H.264, MOV, MPEG4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Audio formats supported	PCM
Internal memory	0 MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display resolution (numeric)	921000 pixels
Magnification	0.78 x
Viewfinder type	Optical
USB version	2.0
Product color	Bronze
Scene modes	Beach, Candlelight, Children, Close-up (macro), Dawn, Dusk, Night landscape, Night portrait, Party (indoor), Portrait, Self-portrait, Snow, Sports, Sunrise, Sunset, Landscape (scenery)
Photo effects	Neutral, Vivid
White balance	Auto, Cloudy, Fluorescent, Incandescent, Manual, Shade, Sunny
Shooting modes	Aperture priority, Auto, Manual, Movie, Program, Scene, Shutter priority
Camera playback	Highlights, Movie, Single image, Slide show, Thumbnails
Self-timer delay	2, 5, 10, 20 s
Camera file system	DCF 2.0, DPOF 1.1, Exif 2.3
On Screen Display (OSD) languages	ARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, KOR, NOR, POL, POR, RUM, RUS, SWE, THA, TUR, UKR
Battery type	EN-EL14
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 85 %
Cables included	AV, USB

Weight and Dimensions

Depth	78 mm
Width	129 mm
Height	98 mm
Weight	555 g
