Chapter 2 Part Names and Microscopy Procedures (With Epi-illumination Attachment Mounted)
2.3 Bright-Field Microscopy
29
2
9
Set a specimen and move the
portion to be viewed into the
optical path.
10
Focus on the specimen.
11
Adjust the diopter and the
interpupillary distance.
Refer to "8. Diopter Adjustment" and "9.
Interpupillary Distance Adjustment" in the separate
Reference manual.
12
Focus and center the condenser.
Refer to "11. Adjustment of Condenser Position" in
the separate Reference manual.
Set a specimen and secure in
place using the specimen holder.
Focus on the specimen using
the coarse and fine focus knobs.
Center the condenser
using the condenser
centering screws.
Focus the condenser
using the condenser
focus knob.
Field dia
