Chapter 1 Nomenclature of Each Part
3
1
* The main body in this figure is an example of ECLIPSE E200 MV RS.
* The light source for E200 MV series is halogen lamp, and the light source for E200LED MV
series is white LED.
(2) Eyepieces
(3) Eyepiece Tube
(1) Main Body
(4) Objectives
(5) Condenser
(6) Field Lens Unit
(7) Lamp
(8) Power Cord
